B2 BOMBARDER DAC

THE B2 BOMBER DIGITAL/ANALOG CONVERTER

The B2 BOMBER DAC is the result of tireless digital-to-analog research and development. As a result, the B2 DAC features unique discrete Class A operational amplifiers with passive filtering. This makes the B2 DAC ideal for monitoring. Couple this with state-of-the-art conversion technology and the B2 BOMBER DAC delivers hitherto unheard-of sonic purity and dynamics.

As a complement to the B2 ADC, the B2 DAC punches you in the chest with bass, while 3D spatiality and stereo spread provide incredible detail across the entire spectrum. Add to that a sweet tone that pleases your ears and you have a unit you will instantly fall in love with! Both the B2 ADC and B2 DAC feature identical, incredibly low jitter clocking, precision metering, and stepped attenuators. Couple the B2 ADC with the B2 DAC and you have the B2 Bomber Master Signal Chain, a force to be reckoned with!

B2 BOMBER DAC Features:

• 44.1k Hz to 192k Hz, 24-bit, 2-channel DAC
• NextGen BOPA8 all discrete op amps
• Passive filters
• All class A
• Zero capacitor signal path
• Audiophile-quality 6-position attenuator with standard headroom settings
• High definition measurement with simultaneous RMS and peak indication
• Dante, 2 AES inputs, SPDIF and Toslink
• BNC wordclock input with two extremely low jitter clock outputs
• Frequency response at 48kHz sampling rate is 10Hz to 22kHz, +/- 0.1dB
• Frequency response at 96 kHz sampling rate is 10 Hz to 30 kHz, +/- 0.1 dB, -0.3 dB to 40 kHz
• Frequency response at 192 kHz sampling rate is 10 Hz to 30 kHz, +/- 0.1 dB, -1.5 dB to 90 kHz
• 115 dB dynamic range
• -96dB THD+N, full scale output = +22dBU
• Rugged design, made in the USA
